Table 8-18 Set three-wire control, enable/clockwise/counterclockwise rotation in quick
commissioning
Parameter Description
p0015=19 Macro drive unit
Assigning digital inputs to the commands:
• Digital input0: Enable/OFF1
• Digital input1: ON clockwise rotation
• Digital input2: ON counter-clockwise rotation
Default setting of the interfaces (Page92)
Parameter
Parameter Description Factory setting
r0722.0…n CO/BO: CU digital inputs, status -
p0840[C] BI: ON/OFF (OFF1) 0
p1113[C] BI: Setpoint inversion 0
p3330[C] BI: 2/3 wire control command 1 0
p3331[C] BI: 2/3 wire control command 2 0
p3332[C] BI: 2/3 wire control command 3 0
r3333.0…n CO/BO: 2/3 wire control control word -
p3334 2/3 wire control selection
3: Three-wire control enable/clockwise/counterclockwise ro‐
tation
0
Advanced commissioning
8.5Controlling clockwise and counter-clockwise rotation via digital inputs
SINAMICS G120C Converters
Operating Instructions, 02/2023, FW V4.7 SP14, A5E34263257B AK 209
