4.10.8 This is how you connect the DC link busbars and 24 V busbars
Connecting additional components
The following steps are necessary to connect a component to the DC link and the 24 V busbars
of the S120 Combi.
Note
When commissioning a drive line-up the following must be observed
The following points must be complied with before commissioning the drive line-up:
● The outer DC link side cover is inserted at the connected component.
● The protective cover of the connected component is closed.
● The front cover of the S120 Combi has been reinstalled.
Note
Attach the touch protection for the DC link busbars
After removing the additional components, before recommissioning the system, the touch
protection of the DC link busbars on the S120 Combi power module must be reinstalled. The
touch protection can be ordered as a spare part.
Service cases - hardware
4.10 SINAMICS S120 Combi
Software and hardware
Service Manual, 08/2018, 6FC5397-5DP40-6BA1 149
