4.18 Terminal Modules
4.18.1 TM54F status displays
Status displays
The Terminal Module TM54F has the following status displays, which provide information
about the module state:
State Description, cause Remedy
RDY L1+, L2+ L3+
Off –- –- Electronics power supply is missing or outside permissible
tolerance range.
–-
Continuous
green light
–- –- The component is ready for operation and cyclic DRIVE-
CLiQ communication is taking place.
–-
Orange con‐
tinuous light
–- –- DRIVE-CLiQ communication is being established. –-
Continuous
red light
–- –- At least one fault is present in this component.
Note:
The LED is controlled irrespective of the corresponding
messages being reconfigured.
Remove and ac‐
knowledge fault.
Green / red
flashing light
0.5 Hz
–- –- Firmware is being downloaded. –-
Flashing light
2 Hz
–- –- Firmware download has been completed. Wait for POWER
ON
Carry out a
POWER ON.
Green/or‐
ange
Flashing light
- OR -
Red/orange
Flashing light
–- –- Component recognition via LED is activated (p0154).
Note:
Both options depend on the LED status when activated via
p0154 = 1.
–-
–- On –- The sensor power supply that can be dynamized is func‐
tioning fault-free.
–-
–- Continuous
red light
–- There is a fault in the sensor power supply that can be
dynamized.
–-
–- –- On The sensor power supply is operating fault-free. --
–- –- Continuous
red light
There is a fault in the sensor power supply. --
Service cases - hardware
4.18 Terminal Modules
Software and hardware
220 Service Manual, 08/2018, 6FC5397-5DP40-6BA1
