4.16.5 SMC30 status displays
Status displays
The Sensor Module Cabinet-Mounted SMC30 has the following status displays, which provide
information about the module state:
LED Color State Description, cause Remedy
RDY - OFF Electronics power supply is missing or outside
permissible tolerance range.
–
Green Continuous light The component is ready and cyclic DRIVE-CLiQ
communication is taking place.
–
Orange Continuous light DRIVE-CLiQ communication is being establish‐
ed.
–
Red Continuous light This component has at least one fault. Remove and acknowl‐
edge fault.
Note:
The LED is controlled irrespective of the corre‐
sponding messages being reconfigured.
Green/red Flashes at 0.5 Hz Firmware is being downloaded. –
Flashes at 2 Hz Firmware download has been completed.
Wait for POWER ON
Carry out a POWER
ON.
Green/orange
or red/orange
Flashing Component recognition via LED is activated
(p0144)
–
Note:
Both options depend on the LED status when
module recognition is activated via p0144 = 1.
OUT > 5 V - OFF Electronics power supply is missing or outside
permissible tolerance range.
Power supply ≤ 5 V
-
Orange Continuous light Electronics power supply for measuring system
available.
Power supply >5 V.
-
Notice:
It must be ensured that it is permissible to oper‐
ate the connected encoder with a 24 V power
supply. If an encoder that is designed for a 5 V
supply is operated with a 24 V supply, this can
destroy the encoder electronics.
Service cases - hardware
4.16 Sensor Modules Cabinet
Software and hardware
206 Service Manual, 08/2018, 6FC5397-5DP40-6BA1
