Siemens SIPROCESS GA700 Quick Start

Quick Start
Compact Operating Instructions, 05/2018, A5E31805656-06
119
Technical specifications
11
11.1
Determining the technical specifications
The technical specifications are obtained based on the specifications of DIN EN 61207-1.
Unless specified otherwise, the data listed below relates to the following measurement
conditions.
Technical specifications
OXYMAT 7
ULTRAMAT 7
CALOMAT 7
Ambient temperature
25 °C
Ambient pressure Atmospheric (approx. 1 000 hPa)
Sample gas flow 0.6 Nl/min; Nl = Standard liter
Sample gas humidity Dew point < -40°C
Site of installation Free of vibration, shock and
impact
Vibration- and
impact-free
Vibration- and
impact-free
Reference gas Nitrogen (N
2
) Standard: Nitrogen (N
2
)
Option: freely selectable
1)
-
Reference application - - Hydrogen in nitrogen
(H
2
in N
2
)
2)
1)
For devices with filled reference gas side
2)
The technical specifications for time and measuring response as well as for the influencing variables can sometimes
differ significantly for other gas mixtures
11.2
Technical specifications of rack-mounted housing
Table 11- 1 Rack-mounted enclosure: General technical specifications
General
Installation position
Horizontal
Weight
Approx. 8.5 kg
Degree of protection
IP20 according to EN 60529
Table 11- 2 Rack-mounted enclosure: Electrical characteristics
Electrical characteristics
Auxiliary power supply 100 to 240 V AC (nominal range of use 85 to 264 V)
50 to 60 Hz (nominal range of use 47 to 63 Hz)
Power consumption
Max. 280 VA
