Siemens SIPROCESS GA700 Quick Start

Technical specifications
11.4 Technical specifications of analyzer modules
Quick Start
Compact Operating Instructions, 05/2018, A5E31805656-06
127
Table 11- 20 OXYMAT 7: Gas connections
Gas connections
With hoses Plastic screw connection for plastic pipe or hose 4 mm /
6 mm
With pipes
Connecting socket for 6 mm pipe
Table 11- 21 OXYMAT 7: Parts in contact with sample gases
Materials of wetted
parts
OXYMAT 7
OXYMAT 7 high-temperature
Sample chamber Stainless steel:
• Plates: Material No. 1.4571
• Screw-in glands: Material No.
1.4404
Hastelloy:
• Plates: Material No. 2.4602
• Screw-in glands: Material No.
2.4819
Stainless steel:
• Plates: Material No. 1.4571
Hastelloy:
• Plates: Material No. 2.4602
Gas
path
With hoses
FPM
-
With pipes Stainless steel:
• Pipes: Material No. 1.4404
• Gas connections: Material No.
1.4571
Hastelloy:
• Pipes: Material No. 2.4602
• Gas connections: Material No.
2.4819
Stainless steel:
• Pipes: Material No. 1.4404
• Screw-in glands: Material No.
2.4819
Hastelloy:
• Pipes: Material No. 2.4602
• Screw-in glands: Material No.
2.4819
Sealing material
FKM (e. g. Viton) or FFKM (Kalrez 6375)
11.4.2
Technical data ULTRAMAT 7
Table 11- 22 ULTRAMAT 7: General technical specifications
General
ULTRAMAT 7
ULTRAMAT 7 high-temperature
Information on the smallest
span
See module nameplate
Max. power consumption
≤ 30 W
≤ 120 W
Weight (only module)
Max. 5.2 kg (standard version)
