Quick Start
Compact Operating Instructions, 05/2018, A5E31805656-06
7
These compact operating instructions are a brief summary of important features, functions
and safety instructions, and contain all the information required for safe use of the device.
This is information on the mounting, connection, commissioning, operation, maintenance and
servicing of the device.
These compact operating instructions are aimed at qualified personnel who were instructed
and trained on all types of work on the device in non-hazardous areas and possible dangers
in case of improper behavior.
It is your responsibility to read the compact operating instructions thoroughly and to
understand them before starting any work. To guarantee correct handling, you should
become acquainted with the principle of operation of the gas chromatograph.
The compact operating instructions belong to the device. Keep them in the direct vicinity of
the device.
To achieve optimum usage of the device, read the detailed version of the operating
instructions: → References (Page 135).
The following table includes information on the different editions of this document.
Table 1- 1 History
01/2013 First edition
05/2014 Expansion option modules OM 1.1 and OM 2.2 (analog inputs, digital inputs, digital out-
05/2015 Extension for analyzer modules CALOMAT 7 and ULTRAMAT 7
03/2016 Additional module combinations for CALOMAT 7 and ULTRAMAT 7.
Extended ULTRAMAT 7 area of application: measurement of components NO, N
2
O,
2
4
2
4
3
06/2017 ULTRAMAT 7: Measurement of two components simultaneously.
Corrosion resistant versions of ULTRAMAT 7 and OXYMAT 7
Cleaned for O
2
: Variants with specially cleaned gas path for sample gases with high
05/2018 Wall-mounted device: Expansion with high-temperature OXYMAT 7 and ULTRAMAT 7
analyzer modules.
