Introduction
1.3 Purpose
8
Quick Start
Compact Operating Instructions, 05/2018, A5E31805656-06
The device is designed for the concentration analysis of gases in gas mixtures. Depending
on the installed analyzer module, different gases can be examined.
Use the device only for measuring/analysis of gas concentrations in gas mixtures according
to the information in section "Technical specifications (Page 119)".
s device meets the requirements of NAMUR Recommendation 53.
Note
Use in home environment
This equipment of Class A Group 1 is intended solely for use in industrial areas.
If used in homes, the device may cause radio interference.
Note
For more information on the compatibility of the hardware and firmware, refer to:
Siemens Industry Online Support (
https://support.industry.siemens.com/cs/de/en/ps/17731).
You will find more information in the operating instructions, see "References (Page 135)".
These compact operating instructions only cover
-explosion-proof SIPROCESS GA700
devices. You can find information on explosion-proof SIPROCESS GA700 devices in the
compact operating instructions "Devices in explosion-proof version", see
Table A-5
References 5 - Compact Operating Instructions Ex (Page 136).
A SIPROCESS GA700 device comprises of a basic device (enclosure) into which up to two
exchangeable analyzer modules can be inserted. The basic device can be delivered in two
variants: As a 19'' rack-mounted enclosure with three height units or as an enclosure for wall
mounting. The analyzer modules are selected in accordance with the measuring task and
local conditions.
The following analyzer modules are available for basic devices:
● Standard analyzer modules OXYMAT 7, ULTRAMAT 7 and CALOMAT 7 for rack-
mounted devices and wall-mounted devices; up to two analyzer modules possible per
basic device.
● High-temperature analyzer modules OXYMAT 7 and ULTRAMAT 7 only for wall-mount
ed
dev
ices; only one analyzer module possible per wall-mounted device.
