Siemens SIPROCESS GA700 Quick Start

Technical specifications
11.4 Technical specifications of analyzer modules
Quick Start
Compact Operating Instructions, 05/2018, A5E31805656-06
131
11.4.3
CALOMAT 7 technical specifications
Table 11- 33 CALOMAT 7: General technical specifications
General
Information on the smallest span
See module nameplate
Power consumption
< 20 W
Weight
Approx. 3 kg
Electrical safety
In accordance with DIN EN 61010-1
Max. EMC error during operation of
one and/or two CALOMAT 7 units
2.0% according to EN 61326-1 (2013)
Table 11- 34 CALOMAT 7: Measuring ranges
Measuring ranges
Number of measuring ranges
Max. 4; parameters can be assigned freely
Note
The following metrological data apply to the gas pair H
2
in N
2
. With other gas pairs, these data may
differ from the possible measuring spans, the time behavior and the measurement behavior as well
as the influencing variables.
Parameters can be assigned in the
measuring ranges
Smallest possible span
0.5% H
2
in N
2
Largest possible span
100% H
2
in N
2
Smallest possible span with sup-
pressed zero point
5% (e.g. 95 to 100%) H
2
in N
2
Table 11- 35 CALOMAT 7: Gas inlet conditions
Gas inlet conditions
Sample gas pressure
700 to 1 200 hPa (absolute)
Pressure loss between sample gas
inlet and sample gas outlet
< 50 hPa at 1.5 l/min
Sample gas flow
30 to 90 l/h (0.5 to 1.5 l/min)
Sample gas temperature and humidity 0 to 70 °C with relative humidity < 90 %, avoid condensa-
tion in the gas path (moisture content results in measure-
ment errors)
Table 11- 36 CALOMAT 7: Temperature of sample chamber and gas path
Temperature of sample chamber and gas path
Gas path 5 K above ambient temperature
Standard version 72 °C
