Appendix
A-2 7SJ62 Manual
C53000-G1140-C121-1
A.1 Ordering Information and Accessories
Number of Binary Inputs and Outputs
8 Binary Inputs, 8 Binary Outputs, 1 Live Status Contact 1
11 Binary Inputs, 6 Binary Outputs, 1 Live Status Contact 2
Nominal Current
I
N
= 1 A 1
I
N
= 5 A 5
Power Supply, Binary Input Pickup Threshold Setting
24 to to 48 VDC, Binary Input Threshold 17 V 2
60 to 125 VDC, Binary Input Threshold 17 V 4
110 to 250 VDC, 115 VAC, Binary Input Threshold 73 V 5
220 to 250 VDC, 230 VAC, Binary Input Threshold 73 V 6
Construction
Surface-mounting case for panel, 2 tier terminals top/bottom B
Flush-mounting case for panel/cubicle, plug-in terminals (2/3 pin connector) D
Flush-mounting case for panel/cubicle, screw-type terminals (ring lugs) E
Region-Specific Default/Language Settings and Function Versions
Region DE, 50 Hz, IEC, Language German (Language can be changed) A
Region World, 50/60 Hz, IEC/ANSI, Language English (Language can be changed) B
Region US, 60 Hz, ANSI, Language Americal English (Language can be changed) C
Region DE, 50 Hz, IEC, Language German (Language cannot be changed) M
Region World, 50/60 Hz, IEC/ANSI, Language English (Language cannot be changed) N
Region US, 60 Hz, ANSI, Language Americal English (Language cannot be changed) P
System Interface - Rear Ports
No system interface 0
IEC-Protokoll, RS232 1
IEC-Protocol, RS485 2
IEC-Protocol, Optical, 820 nm, ST-Connector 3
Profibus FMS Slave, RS485 4
Profibus FMS Slave, Optical, Single Ring, ST-Connector
1)
5
1)
Profibus FMS Slave, Optical, Double Ring, ST-Connector
1)
6
1)
DIGSI 4/Modem Interface - Rear Ports
No rear DIGSI 4-interface 0
RS232 1
RS485 2
Optical, 820 nm, ST-Connector 3
Mean and Min/Max Metering/Fault Recording
Fault Recording 1
Fault Recording, mean values, min/max values 3
1)
not available if “B” is in position 9.
See Page A-3
_
7SJ62
67 8 13 151614
_
9101112
SIPROTEC 4 Multifunction Protection with Controls Order No.
