Appendix C: Communications via PROFIBUS
C.8 Status byte
SITRANS LR250 (PROFIBUS PA)
Operating Instructions, 08/2014, A5E32221386-AC
269
C.8
Status byte
In PROFIBUS PA there are two possible types of status byte:
●
status byte
: originally defined in Profile Standard V3.0
●
condensed status
: an alternative status byte defined in Profile Standard V3.01
You can choose which type of status byte will be returned, by enabling or disabling
Condensed
Status (3.4.)
: see
Enable (3.4.1.)
for details. When Condensed Status is disabled, Status Byte
will be returned, and the following codes will be used.
Status Codes for good quality
Values in hex
notation
Description
0x80
Data is GOOD.
0x84
A parameter in the function block has been changed: status active for 10 s
0x89
Active low warning.
0x8A
Active high warning.
0x8D
Active low alarm.
0x8E
Active high alarm.
Status Codes for Uncertain Quality
Values in hex
notation
Description
0x4B
Value is a substituted value (normally used in Failsafe).
0x4C/0x4F
Initial value.
0x47 Last usable value.
Status Codes for Bad Quality
Values in hex
notation
Description
0x10 The LOE timer has expired: this could be caused by LOE or by a sensor
malfunction: value is BAD.
0x01 There is an error in the configuration of the function blocks in PROFIBUS
PA
a)
.
0X1F The function block, or the transducer block, has been placed out of
service.
a)
This could happen when a firmware download has been done, but a system reset has not been
done. This could also happen if the function blocks are not configured properly using the handheld
programmer, PDM or acyclic services.
