Remote operation
7.1 Operating via SIMATIC PDM
SITRANS LR250 (PROFIBUS PA)
76 Operating Instructions, 08/2014, A5E32221386-AC
7.1.1.1
Features of SIMATIC PDM Rev. 6.0, SP4 or higher
The graphic interface in the device makes monitoring and adjustments easy.
Feature
Function
Quick Start (Page 78) Device configuration for simple applications
Echo Profile Utilities (Page 84) Easy access to echo profile viewing/comparison, TVT shaping,
auto false echo suppression and echo setup
Auto False Echo Suppression
(Page 87)
Screen out false echoes
TVT Shaper (Page 86) Manual TVT adjustment
Process Variables (Page 97) Monitor process variables and level trend
Security (Page 103) Protect security and communication parameters from
modification by the maintenance user
7.1.1.2
Features of SIMATIC PDM Rev. 5.2, SP1
SIMATIC PDM Rev. 5.2 SP1 is supported only for basic configuration and troubleshooting. For
advanced features such as the Quick Start wizard, Rev. 6.0 SP3 HF2 or higher is required.
7.1.1.3
SIMATIC PDM Version
Check the support page of our website to make sure you have the latest version of SIMATIC
PDM, the most recent Service Pack (SP) and the most recent hot fix (HF): SIMATIC PDM
Version (https://support.automation.siemens.com). Browse to
Product Information > Automation
Technology > Process control systems > SIMATIC PCS 7 > System components > SIMATIC
PDM.
7.1.2
Electronic Device Description (EDD)
7.1.2.1
Updating the Electronic Device Description (EDD)
You can locate the EDD in Device Catalog, under
Sensors/Level/Echo/SiemensMilltronics/SITRANS LR250
. The EDD revision must match the
Firmware revision in the device.
