Siemens Sitrans LR250 User Manual

Appendix C: Communications via PROFIBUS
C.10 Diagnostics
SITRANS LR250 (PROFIBUS PA)
Operating Instructions, 08/2014, A5E32221386-AC
273
C.10.3
Extended mode diagnosis
Extended Mode Diagnosis
Hex values
Byte
Bit
Description
Indication class
a)
0x01000000
0
0
Electronics failure
R
0x02000000
1
Mechanical failure
R
0x04000000
2
Motor Temperature too high
R
0x08000000
3
Electronics temperature too high
R
0x10000000
4
Memory error
R
0x20000000
5
Measurement failure
R
0x40000000
6
Device not initialized (no calibration)
R
0x80000000 7 Self calibration failed R
0x00010000
1
0
Zero point error (limit position)
R
0x00020000
1
Power supply failure (electrical, pneumatic)
R
0x00040000
2
Configuration invalid
R
0x00080000
3
New startup carried out (Warm Start)
A
0x00100000
4
Restart carried out (Cold Start)
A
0x00200000
5
Maintenance required
R
0x00400000
6
Characterization invalid
R
0x00800000 7 Set to 1 (one), if the Ident_Number of the running
cyclic data transfer and the value of Physical
Block IDENT__NUMBER_SELECTOR parameter
are different.
R
2
0 to 7
Reserved for use within the PNO
3
0 to 6
Reserved for use within the PNO
0x00000080
7
More diagnosis information is available
a)
R
indicates the message remains active as long as the reason for the message exists.
A
indicates the message will automatically reset after 10 seconds.
Values of the DIAGNOSIS bit:
0 = not set;
1 = set
