Commissioning
6.2 Operating via the handheld programmer
SITRANS LR250 (PROFIBUS PA)
54 Operating Instructions, 08/2014, A5E32221386-AC
Power up the device. A transition screen showing first the Siemens logo and then the current
firmware revision is displayed while the first measurement is being processed.
Press
to toggle between Measurement and Program mode.
Handheld programmer functions
The radar device carries out its level measurement tasks according to settings made via
parameters. The settings can be modified locally via the Local User Interface (LUI) which
consists of an LCD display and a handheld programmer.
A Quick Start Wizard provides an easy step-by-step procedure to configure the device for a
simple application. Access the wizards:
● locally [see Quick Start Wizard via the handheld programmer (Page 63)]
● or from a remote location [see Quick Start Wizard via SIMATIC PDM (Page 78)]
For more complex setups see Application Examples (Page 67), and for the complete range of
parameters see Parameter Reference (Page 107).
