⇒ All parameters can be saved as a backup file on the hard disk. If a module is replaced, the
backup file can be downloaded to the new module within a few seconds. The new module is
right back to the calibrated state - without repeated calibration.
7.5 Service with the SIWATOOL program
You can use the SIWATOOL program to commission the scale independently of the SIMATIC
automation system. You require an RS485/USB converter in order to connect the PC to the
SIWAREX (see section Ordering data (Page 123)). You can then connect the RS485 interface
of the SIWAREX to the USB port of the PC.
The SIWATOOL program is included in the configuration package.
Install SIWATOOL for commissioning (part of the SIWAREX WP321 configuration package,
see section Ordering data (Page 123)) on your PC.
7.5.1 Windows and functions of SIWATOOL
① Control elements for SIWATOOL and operation of
the scale
③ Offline values of the SIWAREX module
② Parameter list of the SIWATOOL module ④ Online values of the connected SIWAREX module
Figure 7-22 Layout of the SIWATOOL user interface
For sending, receiving and transferring, select the corresponding data record and call the
command list with a right mouse click.
Commissioning
7.5 Service with the SIWATOOL program
SIWAREX WP321
56 Operating Instructions, 08/2019, A5E33715669A-AD
