Variable Note Type Length
(bytes)
Rw Default Min. Max.
Load cell input 1: Excita‐
tion current (mA)
[LOAD_CELL_IN‐
PUT_1_EXCITA‐
TION_CURRENT]
Current excitation current
(mA) which is required for
the supply of the load cell
FLOAT 4 r 0 0 1999
Load cell input 2: Excita‐
tion current (mA)
FLOAT 4 r 0 0 1999
Load cell input 3: Excita‐
tion current (mA)
FLOAT 4 r 0 0 1999
Load cell input 4: Excita‐
tion current (mA)
FLOAT 4 r 0 0 1999
Temperature (°C)
[TEMPERATURE]
Current temperature (°C)
of the SIWAREX DB elec‐
tronic system
FLOAT 4 r 0.0 -50 +150.0
8.21 DR 82 SIWAREX DB device information
You cannot make any entries in data record DR 82. This data record only provides information
on the inner workings of the SIWAREX DB. This information is used to identify SIWAREX DB
at the manufacturer plant. The entries in the data record are of no importance to the user for
operation.
Table 8-18 Assignment of data record DR 82
Variable Note Type Length
(bytes)
Rw Default Min. Max.
Data record number
[DR_NO]
Contains no. of data re‐
cord
USHORT 2 R 82 - -
Length [DR_LEN] Data record length infor‐
mation
USHORT 2 R 184 - -
Application [APPL_ID] Information on which
application the data re‐
cord belongs to
USHORT 2 R 101 - -
Version identifier
[DR_VERSION]
Information on the cur‐
rent data record version
USHORT 2 r 1 1 65635
Order number
[ORDER_NO]
Order number
SIWAREX DB
CHAR[32] 32 r „ „ - -
Serial number
[SERIAL_NO]
Serial number
SIWAREX DB
CHAR[32] 32 r „ „ - -
FW version number
[FW_VERSION]
FW version number
SIWAREX DB
CHAR[16] 16 r „ „ - -
HW version
[HW_VERSION]
HW version
SIWAREX DB
CHAR[16] 16 r „ „ - -
Hardware device ID
[HW_DEVICE_ID]
Hardware device ID
SIWAREX DB
USHORT 2 r 0 0 31
Scale parameters and functions
8.21 DR 82 SIWAREX DB device information
SIWAREX WP321
96 Operating Instructions, 08/2019, A5E33715669A-AD
