8.20 DR 81 SIWAREX DB process status advanced
Current states and process values in the scales can be monitored using SIWAREX DB specific
advanced process values and process values from data record DR 80.
Table 8-17 Assignment of data record DR 81
Variable Note Type Length
(bytes)
Rw Default Min. Max.
Data record number
[DR_NO]
Contains no. of data re‐
cord
USHORT 2 R 81 - -
Length [DR_LEN] Data record length infor‐
mation
USHORT 2 R 64 - -
Application [APPL_ID] Information on which ap‐
plication the data record
belongs to
USHORT 2 R 101 - -
Version identifier
[DR_VERSION]
Information on the current
data record version
USHORT 2 r 1 1 65635
Excitation voltage EXC (V)
[EXCITATION_VOLT‐
AGE]
Excitation voltage EXC
(V) with which the load
cells are supplied
FLOAT 4 r 0 0 10000
Load cell input 1: Impe‐
dance (Ohm)
[LOAD_CELL_IN‐
PUT_1_IMPEDANCE]
Current impedance
(Ohm) of connected load
cell
FLOAT 4 r 0 0 20000
Load cell input 2: Impe‐
dance (Ohm)
FLOAT 4 r 0 0 20000
Load cell input 3: Impe‐
dance (Ohm)
FLOAT 4 r 0 0 20000
Load cell input 4: Impe‐
dance (Ohm)
FLOAT 4 r 0 0 20000
Load cell input 1: Sense
voltage SEN (V)
[LOAD_CELL_IN‐
PUT_1_SENSE_VOLT‐
AGE]
Current voltage (V) which
is measured between
SENSE+ and SENSE- of
the load cell
FLOAT 4 r 0 0 10000
Load cell input 2: Sense
voltage SEN (V)
FLOAT 4 r 0 0 10000
Load cell input 3: Sense
voltage SEN (V)
FLOAT 4 r 0 0 10000
Load cell input 4: Sense
voltage SEN (V)
FLOAT 4 r 0 0 10000
Scale parameters and functions
8.20 DR 81 SIWAREX DB process status advanced
SIWAREX WP321
Operating Instructions, 08/2019, A5E33715669A-AD 95
