Rated Output Current 100% rated current non-stop output
Max. Overload Current
Model G: 150% rated current for 1 minutes, 180% rated current for 2 seconds
Model P: 120% rated current for 1 minutes, 150% rated current for 2 seconds
Basic Control Functions
Control Mode V/F, SVC
Input Mode Frequency (Speed) input, torque input
Running Mode Keypad, control terminals (2-wire sequence, 3-wire sequence), RS485
Frequency Control Range 0.00～600.00Hz
Input Frequency
Resolution
Numeric input:0.01Hz, analog input: 0.1% of maximum frequency
Governor Deflection 1:50(V/F), 1:100(SVC)
Speed Control Accuracy ±0.5% rated synchronous speed
Acceleration/Deceleration
Time
0.01~600.00 seconds/minutes
V/F Features Rated output voltage: 20%~100% adjustable, frequency base :20Hz~600Hz adjustable
Torque Boost Automatic torque boost, fixed torque boost curve, customer defined V/F curve scaling
Start Torque 150%/1Hz(V/F),150%/0.5Hz(SVC)
Torque Control Accuracy ±15% rated torque (SVC1)
AV R AVR is active while output voltage remains unchanged if input voltage is varying.
Automatic Current Limit Automatically limit output current, avoid frequent overcurrent tripping
DC Brake Brake frequency:0.1~60Hz, brake time:0~30S, brake current:0~100% rated current
Signal Input Source
Communication, analog voltage, analog current, preset speed, simple PLC and their
combinations
Special
Function
Control
Textile Wobbulation Realize textile wobbulation functions like wobbulation range, time and jump
Droop Control With increase of load, the speed droops, suitable for one machine driven by multi-motor
Function of Input and
Output
Reference Power 10V/20mA
Terminal Control Power 24V/150mA
Numeric Input Terminals 7 programmable numeric input terminals
Analog Input Terminals 4 analog inputs:2 voltage inputs (0~10V), and 2 current inputs(0~20mA)
Numeric Output Terminal
2 OC outputs and 1 relay output are programmable. Maximum output current of OC:
50mA. Relay contact capacity: 250VAC/3A or 30VDC/1A. When relay acts, EA-EC is
NO, and EB-EC is NC.
Analog output Terminals 2 programmable analog output terminals can output 0~10V or 0~20mA
Keypad
Display
LED Human interactions with displays and control actuators
Parameter Copy Upload and download parameter information of the inverter, copy parameters rapidly.
Protections
Protections
Short circuit, overcurrent, overload, overvoltage, undervoltage, phase loss, overheating,
external fault, and etc.
Applica-tion
Conditions
Installation Site
Indoor, with altitude less than1,000 meters, free from dust,corrosive gas, and direct
sunlight
Ambient Temperature
-10℃～+40℃. In the temperature range +40 °C…+50 °C, the rated output current is
decreased by 1% for every additional 1 °C. 20%～90%RH (no condensation)
Vibration ＜0.5g
Storage Temperature -25℃～+65℃
Installation Method Wall mounting, or floor mounting
Degree of Protection IP20
Cooling Method Forced air cooling
