User Manual
EM303A General Purpose Inverter
99
7.4 Group F3: Preset Speed Parameters
No. Function Range Unit Default Type
F3-00 Preset Speed 1 0.00~Fmax/0.0~Fmax Hz 0.00 ●
F3-01 Preset Speed 2 0.00~Fmax/0.0~Fmax Hz 5.00 ●
F3-02 Preset Speed 3 0.00~Fmax/0.0~Fmax Hz 10.00 ●
F3-03 Preset Speed 4 0.00~Fmax/0.0~Fmax Hz 15.00 ●
F3-04 Preset Speed 5 0.00~Fmax/0.0~Fmax Hz 20.00 ●
F3-05 Preset Speed 6 0.00~Fmax/0.0~Fmax Hz 25.00 ●
F3-06 Preset Speed 7 0.00~Fmax/0.0~Fmax Hz 30.00 ●
F3-07 Preset Speed 8 0.00~Fmax/0.0~Fmax Hz 35.00 ●
F3-08 Preset Speed 9 0.00~Fmax/0.0~Fmax Hz 40.00 ●
F3-09 Preset Speed 10 0.00~Fmax/0.0~Fmax Hz 45.00 ●
F3-10 Preset Speed 11 0.00~Fmax/0.0~Fmax Hz 50.00 ●
F3-11 Preset Speed 12 0.00~Fmax/0.0~Fmax Hz 50.00 ●
F3-12 Preset Speed 13 0.00~Fmax/0.0~Fmax Hz 50.00 ●
F3-13 Preset Speed 14 0.00~Fmax/0.0~Fmax Hz 50.00 ●
F3-14 Preset Speed 15 0.00~Fmax/0.0~Fmax Hz 50.00 ●
Through preset speed control terminals and 15 preset frequency commands, EM330 can
provide 16 preset speeds by combining keypad numeric setting mode and analog setting
mode. Furthermore, it can be adjusted at any time through repeated addition analog input.
Setting Preset Speed Terminals
Ter min al No. Default Function
X3 F2-02 3 Preset Speed Terminal 1
X4 F2-03 4 Preset Speed Terminal 2
X5 F2-04 5 Preset Speed Terminal 3
X6 F2-05 6 Preset Speed Terminal 4
X7 F2-06 10 Inverter Fault Reset
Preset Speed Commands and Preset Speed Terminals
Speed
Preset Speed
Terminal 4
Preset Speed
Terminal 3
Preset Speed
Terminal 2
Preset Speed
Terminal 1
Selected
Frequency
No.
1 OFF OFF OFF OFF Keypad or Analog Setting Defined by F0-06
2 OFF OFF OFF ON Preset Speed 1 F3-00
3 OFF OFF ON OFF Preset Speed 2 F3-01
4 OFF OFF ON ON Preset Speed 3 F3-02
5 OFF ON OFF OFF Preset Speed 4 F3-03
6 OFF ON OFF ON Preset Speed 5 F3-04
7 OFF ON ON OFF Preset Speed 6 F3-05
8 OFF ON ON ON Preset Speed 7 F3-06
To Next Page
