6.2.2 Group F1: Motor Parameters
No. Function Range Unit Default
Type
F1-00 Motor Type
0: AC induction motor
1: Not used
0
〇
F1-01 Motor Rated Power 0.40~480.00 kW XXXX
〇
F1-02 Motor Rated Voltage 60~660 V XXX
〇
F1-03 Motor Rated Current 0.1~1500.0 A XXXX
〇
F1-04 Motor Rated Frequency 20.00~600.00/20.0~6000.0 Hz XXXX
〇
F1-05 Motor Rated Speed 1~30000 rpm XXXX
〇
F1-06 Motor Wiring Mode
0: Y Wiring
1: Δ Wiring
X
〇
F1-07 Motor Rated Power Factor 0.50~0.99 X
〇
F1-08 Idling Excitation Current 0.1~1500.0 A XXXX
〇
F1-09 Rated Torque Current 0.1~1500.0 A XXXX
〇
F1-10 Stator Resistance R1 0.01~300.00 Ω XXXX
〇
F1-11 Rotator Resistance R2 0.01~300.00 Ω XXXX
〇
F1-12
Stator& Rotor Leakage
Inductance Ls
0.1~3000.0 mH XXXX
〇
F1-13
Stator& Rotor Mutual
Inductance Lm
0.1~3000.0 mH XXXX
〇
F1-14 Motor Efficiency 30.0~99.0 % XXXX
〇
F1-15 Autotuning Parameters
0:No autotuning
1:Staionary autotuning
2: Rotational autotuning
0
〇
F1-16 Inverter Address
0～247, 0：Broadcasting Address
1
〇
F1-17 Communication Bit Rate
0: 4800
1: 9600
2: 19200
3: 38400
bps 1
〇
F1-18
Communication Parity
Mode
0: No parity 1+8+1
1: Even parity 1+8+1+1
2: Odd parity 1+8+1+1
0
〇
F1-19
Master-slave
Communication Mode
0:The inverter is the slave
1:The inverter is the master
0
〇
F1-20
Master Writes the Address
of Slave Inverter
0:Primary Numeric Frequency
F0-07
1:Auxiliary Numeric Frequency
F9-06
0
〇
F1-21
Inverter Receiving
Proportion Coefficient
0.00~600.00 % 100.00 ●
F1-22 Analog Input Gain K1 0.00~600.00 % 100.00 ●
F1-23 Analog Input Gain K2 0.00~600.00 % 0.00 ●
F1-24 Analog Input Gain K3 0.00~600.00 % 100.00 ●
F1-25 Analog Input Gain K4 0.00~600.00 % 0.00 ●
F1-26 Analog Input Gain K5 0.00~600.00 % 0.00 ●
F1-27 Analog Input Gain K6 0.00~600.00 % 0.00 ●
F1-28 Analog Input Gain K7 0.00~600.00 % 0.00 ●
F1-29 Analog Input Gain K8 0.00~600.00 % 0.00 ●
F1-30 Communication Overtime
0（Disabled） 0.1～60.0
S 0 ●
F1-31 Not Used
