User Manual
EM303A General Purpose Inverter
49
6.2.3 Group F2: Input/Output Terminal Parameters
No. Function Range Unit Default Type
F2-00
Multi-function Input Terminal
X1-RUN
See Table 6-1
Functions of Numeric
Multi-function Input
Terminals
1 〇
F2-01
Multi-function Input Terminal
X2-F/R
2 〇
F2-02
Multi-function Input Terminal
X3-D1
3 〇
F2-03
Multi-function Input Terminal
X4-D2
4 〇
F2-04
Multi-function Input Terminal
X5-D3
5 〇
F2-05
Multi-function Input Terminal
X6-FRS
9 〇
F2-06
Multi-function Input Terminal
X7-RST
10 〇
F2-07 Not used
F2-08 VS Input Function Defining 0 〇
F2-09 IS Input Function Defining 0 〇
F2-10 VF Input Function Defining 0 〇
F2-11 IF Input Function Defining 0 〇
F2-12
Multi-function Output Terminal
Y1
See Table 6-2
Functions of Numeric
Multi-function Output
Terminals
0 〇
F2-13
Multi-function Output Terminal
Y2
1 〇
F2-14 Relay Output Terminal R1 9 〇
F2-15 Not Used
F2-16 Analog Output Terminal M0
See Table 6-3
F2-16~F2-20 Analog
Output Full Scale
% 0 〇
F2-17 Analog Output Terminal M1 % 6 〇
F2-18 Not Used
F2-19 Jog Analog Output Terminal M0 % 0 〇
F2-20 Jog Analog Output Terminal M1 % 6 〇
F2-21 Not Used
F2-22 M0 Output Lower Limit 0.00~100.00 % 0.00 ●
F2-23 M0 Output Upper Limit 0.00~100.00 % 100.00 ●
F2-24 M0 Output Gain 0.00~300.00 % 100.00 ●
F2-25 M1 Output Lower Limit 0.00~100.00 % 0.00 ●
F2-26 M1Output Upper Limit 0.00~100.00 % 100.00 ●
F2-27 M1 Output Gain 0.00~300.00 % 100.00 ●
F2-28～F2-31 Not used
