User Manual
EM303A General Purpose Inverter
45
6 Parameter Tables
6.1 Format of Parameter Tables
17 groups of parameter of EM303A: F0, F1, F2, F3, F4, F5, F6, F7, F8, F9, FA, Fb,
FC, Fd, FE, C0, and E0, 32 items in each group.
F0~FE are function setting parameters which consist of two sections. The 1
st
section
F0~F4 are general parameters, and the 2
nd
section F7~FE are advanced parameters.
Group C0 are status monitoring parameters.
Group E0 are fault monitoring parameters.
When F0-27=0, the inverter only displays the parameters of Group F0~F5, C0, and
E0.
When F0-27=1, the inverter displays all parameters.
The 1
st
column is the number of the parameter.
The 2
nd
column is the function of parameter.
The 3
rd
column is the range of parameter.
The 4
th
column is the parameter unit.
The 5
th
column is the parameter default. For instance, XXX represents that the
parameter default varies with the power ratings of inverter.
The 6
th
column is the type of parameter (whether the parameter is editable or not).
Details shown as followings:
“
●” : Parameter editing is permitted when the inverter is running.
“
〇” : Parameter editing is prohibited when the inverter is running.
“
◇”: The inverter can process automatically according to parameter type.
“X”: The parameter is read only.
Unit and Its Abbreviation
HOUR Hour m Meter %
Percentage
★
SQRT
Square
Root
min Minute mm Millimeter rpm
Revolutions
per minute
A Ampere
S Second Hz Herz MAX Maximum V Voltage
mS Millisecond kHz Kiloherz MIN Minimum SECT
Program
Section
mH Millihenry kW Kilowatt bps
Bits per
second
★
The basic value of percentage is the rated value.
