User Manual
EM303A General Purpose Inverter
20
Table 2-2 Overall and Installation Dimensions of EM303A
Model No. W W1 H H1 H2 D D1 D2 d Frame
EM303A-0R7G/1R1P-3CB
140 125 220 205 -- 152 120 161 6 (b)
EM303A-1R1G/1R5P-3CB
EM303A-1R5G/2R2P-3CB
EM303A-2R2G/3R0P-3CB
EM303A-3R0G/4R0P-3CB
EM303A-4R0G/5R5P-3CB
EM303A-5R5G/7R5P-3CB
165 148 250 235 -- 161 126 170 6 (b)
EM303A-7R5G/9R0P-3CB
EM303A-9R0G/011P-3CB
215 150 352 335 317 215 172 224 7 (c)
EM303A-011G/015P-3CB
EM303A-015G/018P-3CB
EM303A-018G/022P-3C
270 200 470 450 424 245 187 254 10 (c)
EM303A-022G/030P-3C
EM303A-030G/037P-3C
EM303A-037G/045P-3C
335 240 550 530 500 245 190 254 10 (c)
EM303A-045G/055P-3C
EM303A-055G/075P-3C
390 300 695 665 635 250 200 259 12 (c)
EM303A-075G/090P-3C
EM303A-090G/110P-3C
560 400 828 803 775 355 255 364 12 (c)
EM303A-110G/132P-3C
EM303A-132G/160P-3C
EM303A-160G/185P-3C
650 400 1060 1034 1000 400 325 409 13 (c)
EM303A-185G/200P-3C
EM303A-200G/220P-3C
EM303A-220G/250P-3C
825 660 1200 1170 1137 400 320 409 13 (c)
EM303A-250G/280P-3C
EM303A-280G/315P-3C
EM303A-315G/355P-3C
1068 870 1213 1183 1150 410 330 419 13 (c)
EM303A-355G/400P-3C
EM303A-400G/450P-3C
Remarks:
z 5 models: EM303A-055~075, EM303A-090~132, EM303A-160~200,
EM303A-220~280, and EM303A-315～400 can be floor-mounted with a chassis
which is in the same width as the inverter. Heights of optional chassis: 120mm,
250mm, 300mm, 300mm and 350mm.
z EM303A-090 or above: power input terminals are on the top, and power output
terminals are at the bottom of the inverter.
