User Manual
EM303A General Purpose Inverter
46
6.2 Parameters
Section 1 General Parameters
6.2.1 Group F0: General Parameters
No. Function Range Unit Default Type
F0-00
(L)
Speed Reference
Input Monitoring
Torque Reference
Input Monitoring
Frequency: 0.00～Fmax/0.0～Fmax
Speed: 0～F*Customer defined
scaling
Torque input: 0.00~Limited torque
Hz
rpm
%
0.00/0
0.0/0
0.00
X
F0-01
(H)
F0-02 Drive Control Mode
0: V/F open loop Control
1: Not used
2: SVC0
3: SVC1
2 〇
F0-03
Setting Input Control
Mode
0: Speed input
1: Torque input
0 〇
F0-04
Start/Stop Control
Options
0: Keypad
1: Terminal
2: RS485
0 〇
F0-05
Terminal Start/Stop
Control Selection
0: RUN-Run, F/R-Forward/Reverse
1: RUN-Forward, F/R- Reverse
2: RUN-NO forward,
Xi-NC stop,
F/R-NO reverse
3: RUN-NO run, Xi-NC stop,
F/R- Forward/Reverse
0 〇
F0-06
Regular Speed
Setting Mode
0: Primary Numeric Frequency
1: VP
2: VS
3: IS
4: Not Used
5: K3*VS+K4*IS
6: K3*VS+K5*VF
7: K4*IS+K6*IF
8: MAX{K3*VS,K5*VF}
9: MAX{K4*IS,K6*IF}
10: K1*VP+K2*(K3*VS+K4*IS+
K5*VF+K6*IF-K8*5V)
1 〇
F0-07
Primary Numeric
Frequency Setting
0.00~Fmax/0.0~Fmax Hz 0.00 ●
F0-08
Motor Running
Direction
0: Forward
1: Reverse
0 ●
F0-09 Acceleration Time 1 0.00~600.00 S/min 15.00 ●
F0-10 Deceleration Time 1 0.00~600.00 S/min 15.00 ●
F0-11
Jog Numeric
Frequency
0.00~Fmax/0.0~Fmax Hz 5.00 ●
F0-12 Jog Acceleration 0.00~600.00 S/min 15.00 ●
