EM303A General Purpose Inverter
75
6.2.17 Group FE: Terminal Function User Defined Parameters
No. Function Range Unit Default Type
FE-00
Numeric Input
Filter Times
0~100； 1=0.50mS 5 〇
FE-01
Terminal Input
Positive/Negative
Logic
X7 X6 X5 X4 X3 X2 X1
00000000 〇
0 0 0 0 0 0 0
0:Positive Logic On at 0V/Off at 24V
1: Negative Logic Off at 0V/ On at 24V
FE-02
X1 Input Delay
Time
0.00~300.00 S 0.00 〇
FE-03
X2 Input Delay
Time
0.00~300.00 S 0.00 〇
FE-04
Analog Input
Signal Options
Ones place: VS input signal options
0: Analog signal input
1: Numeric signal input
Tens place:IS input Signal options
0: Analog signal input
1: Numeric signal input
Hundreds place: VF input signal options
0: Analog signal input
1: Numeric signal input
Thousands place: IF input signal options
0: Analog signal input
1: Numeric signal input
0000 〇
FE-05
Analog Terminal
Input Logic
Ones place: Input terminal VS
0：VS is on at high level input
1：VS is off at low level input
Tens place: Input terminal IS
0：IS is on at high level input
1：IS is off at low level input
Hundreds place: Input terminal VF
0：VF is on at high level input
1：VF is off at low level input
Thousands place: Input terminal IF
0: IF is on at high level input
1: IF is off at low level input
0000 〇
FE-06
Output Signal
Type
Ones place: Y1 output type
0: Level signal
1: Pulse signal
Tens place: Y2 output type
0: Level signal
1: Pulse signal
000 〇
To Next Page
