User Manual
EM303A General Purpose Inverter
59
6.2.8 Group E0: Fault Parameters
No. Function
Trip and Parameter
Description
Unit Default Type
E0-00 Fault Trips
00: No fault
SC: Short circuit
HOC: Instantaneous overcurrent
HOU: Instantaneous overvoltage
SOC: Stable overcurrent
SOU: Stable overvoltage
SLU: Stable undervoltage
ILP: Input phase loss
OL: Overload
OH: Heatsink overheating
OLP: Not used
EXT: External failure
PUP: PID upper limit
PdN: PID lower limit
EEd: Inverter EEPROM failure
EEU:Keypad EEPROM failure
STP:Autotuning cancelled
SFE:Autotuning coast-to-stop
SrE:Stator resistance error
SIE:Idling current error
INP:Internal failure
0 ◇
E0-01
Output Frequency at
Fault
XX.XX/XX.X Hz 0.00 ◇
E0-02
Output Current at
Fault
XXX.X A 0.0 ◇
E0-03
DC Bus Voltage at
Fault
XXXX V 0.0 ◇
E0-04
Running Direction at
Fault
For: Forward, rEV: Reverse 0 ◇
E0-05
Running Status at
Fault
ACC: Acceleration
CON: Constant speed
dEC: Deceleration
0 ◇
E0-06 Stall Status at Fault
0：Normal
UL：Overvoltage stall
CL：Overcurrent stall
0 ◇
E0-07 Working Time at Fault HOUR 0 ◇
E0-08 Last Fault Fault trips 0 ◇
E0-09
Output Frequency at
Fault
XX.XX/XX.X Hz 0.00 ◇
E0-10
Output Current at
Fault
XXX.X A 0.0 ◇
