6.2.5 Group F4: General Parameters of PID
No. Function Range Unit Default Type
F
4-00
PID Regular
Setting Mode
0: Numeric PID Setting
1: VS
2: IS
3: VF
4: IF
5: VP
0 〇
F
4-01
PID Numeric
Setting
0.00~10.00 V
5.00 ●
F
4-02
PID Feedback
Channel
0: VF
1: IF
2: VS
3: IS
0 〇
F
4-03
PID
Monitoring
Options
0: Voltage-V
1: Actual Physical Quantity (V*Display Coefficient)
0 〇
F
4-04
PID Display
Coefficient
0.01~100.00
1.00 ●
F
4-05
PID Positive/
Negative
Setting
0: Positive Setting
1: Negative Setting
0 〇
F
4-06
PID Output
Gain
0.00~100.00 %
100.00 ●
F
4-07
Proportion
Gain GP
0.00~100.00
0.40 ●
F
4-08
Integration
Time GTi
0.000~30.000 0.000:No Integration S
10.000 ●
F
4-09
Differentiation
Time GTd
0.000~10.000 S
0.000 ●
F
4-10
Integration
Function Scale
0.00~100.00 %
100.00 ●
F
4-11
PID Positive
Output Limit
0.00~100.00 %
100.00 ●
F
4-12
PID Negative
Output Limit
0.00~100.00 %
0.00 ●
F
4-13
Menu Display
Control 1
Fd. FC. Fb. FA. F9. F8. F7. F6.
11111111 ● 1 1 1 1 1 1 1 1
0：No Display， 1：Display
F4-14
Menu Display
Control 2
*. *. *. *. *. *. FF. FE.
00000011 ● 0 0 0 0 0 0 1 1
0：No Display， 1：Display
F
4-15
Monitoring
Reference
Selection
**
Estimated
Slip
Estimated
Speed
*
Sync-
Freq.
Inp.
Freq.
Outp.
Freq.
11111111 〇
0 0 1 1 1 1 1 1
0：Absolute Value， 1：+/-
