Service Manual
Original issue
Feb. 2007
Page 18/55
Model
CE-200E
11. Presser Foot Height
１.Lower the feed dog below the needle plate.
２.Raise the presser foot lever.
３.Check and see if clearance between the needle plate and the presser foot is about
5.6mm.
Adjustment
１.Remove the face cover, and raise the presser foot lever.
２.Loosen the screw (A) and adjust the presser foot height moving the presser bar.
３.Tighten the screw securely after checking the presser foot is parallel with the needle
plate.
A
5.6 mm
To Next Page
