Service Manual
Original issue
Feb. 2007
Page 2/55
Model
CE-200E
INDEX
1. Removing cover for circuit board
2. Removing face, bottom and base covers (1)-(2)
3. Removing top cover and thread sensor cover
4. Removing rear cover
5. Removing front cover
6. Removing control panel assembly (1)-(2)
7. Test mode A of sewing machine with thread sensor deactivated.
8. Test mode B of sewing machine for continuous running (1)-(2)
9. Needle bar height
10. Needle threader height (1)-(2)
11. Presser Foot Height
12. Feed-dog height
13. Feed-dog timing (vertical movement)
14. Feed timing (horizontal movement)
15. Positioning of pulse motor for feeding at origin point
16. Adjustment of “0” feed (1)-(2)
17. Adjustment of needle at center position
18. Positioning of stopper for needle at right position
19. Needle timing to shuttle
20. Needle clearance to shuttle (1)-(2)
21. Positioning of zigzag pulse motor at origin point
22. Retaining bracket for bobbin case (1)-(2)
23. Upper thread tension unit
