Service Manual
Original issue
Feb. 2007
Page 46/55
Model
CE-200E
35-1. Test mode B for sewing machine with embroidery
unit for continuous running
*Refer to the section of “Test mode B for sewing machine for continuous running“
● mark is starting point.
Mode 1: Needle position: center position
fixed.
Embroidery hoop moves as shown below.
Mode 2: Needle position: center position
fixed.
Embroidery hoop moves as shown below.
Mode 3: Needle position: center position
fixed.
Embroidery hoop moves as shown below.
Mode 4: Needle position: center position
fixed.
Embroidery hoop moves as shown below.
To Next Page
