Service Manual
Original issue
Feb. 2007
Page 53/55
Model
CE-200E

40-1. Control circuit board and functions
of each connector
Model CE-200Ｅ


23P connector
with CPU
Jumper cord
Start/sto
p,
r
everse SW
