Service Manual
Original issue
Feb. 2007
Page 38/55
Model
CE-200E
28. Adjustment of needle position when machine stops
1. Check to see if the tip of take-up lever is located within a range on thread guide plate
as shown below during its lifting process.
2. Adjust by removing the front cover and loosening a screw holding the control cam
and turning the control cam in either way.
3. Recheck if needle stops at the right position and tighten the screw securely.
Control Cam
To Next Page
