Service Manual
Original issue
Feb. 2007
Page 36/55
Model
CE-200E
26. Oiling in Shuttle area and Needle bar
＊Oiling in Shuttle area
1. Remove Bobbin cover and Needle plate.
2. Remove Bobbin case by lifting out from the left side.
3. Using the brush provided, clean around the whole exposed area, and then apply
a little oil in the place (A)
＊Oiling in Needle bar
1. Remove face cover and then place one or two drops oil at Needle bar clamp (B) & (C).
A
Ｂ
Ｃ
Ｃ
