Singer Futura CE-200E User Manual

Service Manual
Original issue
Feb. 2007
Page 55/55
Model
CE-200E
42. List of electronic parts
Item CE-200E Note
Sewing machine side
Sensor A on top cover 84019
Bobbin winder SW harness 85355
Contorl sensors on main shaft 84018
BH lever switch harness 84027
LED lamp harness 87605
BH positioning switch harness 84029
Sensor B at check-spring 86182
Pulse motor for feed 84006
Positioning switch of pulse motor for feed 84022
Pulse motor for zigzag 84007
Positioning switch of pulse motor for zigzag 84021
Power switch harness (230V) 85333
USB jack harness 84030
Foot control jack harness 84023
Transformer (230V) 84020
23P cable 84024
Embroidery harness 86262
Drawer connector on machine 86270
Main motor 85302
Micro switch harness 84004
CPUcircuitboard
84000
Start/stop switch harness 84026
Control panel circuit board 84002
Enbroidery unit side
Drawer connector on embroidery 47181
Cable for connecting to pulse motors 84032
Circuit board for embroidery unit 84001
Sensor for X-direction movement 84034
Pulse motor of X-direction 84008
Pulse motor of Y-direction 84009
Sensor for Y-direction movement 84011
Hoop switch harness 86312
Flat cable 86308
USB cable 86962
