AnnexeII.MODBUS
©
Communicationaddressand
designationdetails
Note: To authorise a change in conguration: dene adress HEXA E300 as 1000.
AnnexeII-1.MetrologyAffectedbycurrentandvoltagetransformers
Function 3 Codes
Dec.
Address
Hex.
Address
Words
count
Description Unit
50514 C552 2 Phase to Phase Voltage: U12 (load) V/100
50516 C554 2 Phase to Phase Voltage: U23 (load) V/100
50518 C556 2 Phase to Phase Voltage: U31 (load) V/100
50520 C558 2 Simple voltage: V1 (load) V/100
50522 C55A 2 Simple voltage: V2 (load) V/100
50524 C55C 2 Simple voltage: V3 (load) V/100
50526 C55E 2 Frequency: F Hz/100
50528 C560 2 Current: I1 mA
50530 C562 2 Current: I2 mA
50532 C564 2 Current: I3 mA
50534 C566 2 Neutral Current: In mA
50536 C568 2 ∑ Active Power ±: P kW/100 (Signed)
50538 C56A 2 ∑ Reactive Power ±: Q kvar/100 (Signed)
50540 C56C 2 ∑ Apparent Power: S kVA/100
50542 C56E 2 ∑ Power Factor: -: leading et +: lagging: PF 0,001 (Signed)
50544 C570 2 Active Power phase 1 ±: P1 kW/100 (Signed)
50546 C572 2 Active Power phase 2 ±: P2 kW/100 (Signed)
50548 C574 2 Active Power phase 3 ±: P3 kW/100 (Signed)
50550 C576 2 Reactive Power phase 1 ±: Q1 kvar/100 (Signed)
50552 C578 2 Reactive Power phase 2 ±: Q2 kvar/100 (Signed)
50554 C57A 2 Reactive Power phase 3 ±: Q3 kvar/100 (Signed)
50556 C57C 2 Apparent Power phase 1: S1 kVA/100
50558 C57E 2 Apparent Power phase 2: S2 kVA/100
50560 C580 2 Apparent Power phase 3: S3 kVA/100
50562 C582 2 Power Factor phase 1 -: leading and +: lagging : PF1 0,001 (Signed)
50564 C584 2 Power Factor phase 2 -: leading and +: lagging : PF2 0,001 (Signed)
50566 C586 2 Power Factor phase 3 -: leading and +: lagging : PF3 0,001 (Signed)
AnnexeII-2.Energy
Function 3 Codes
Dec.
Address
Hex.
Address
Words
count
Description Unit
50770 C652 2 Total Positive Active Energy (no resetable): Ea+ kWh
50772 C654 2 Total Positive Reactive Energy (no resetable): Er + kvarh
50774 C656 2 Total Apparent Energy (no resetable): Es kVAh
50776 C658 2 Total Negative Active Energy (no resetable): Ea- kWh
50778 C65A 2 Total Negative Reactive Energy (no resetable): Er - kvarh
50780 C65C 2 Partial Positive Active Energy: Ea+ kWh
50782 C65E 2 Partial Positive Reactive Energy: Er + kvarh
50784 C660 2 Partial Apparent Energy : Es kVAh
50786 C662 2 Partial Negative Active Energy : Ea- kWh
