socomec ATyS r User Manual

134
EN
ATYSp - 542001E - SOCOMEC
Dec.
Address
Hex.
Address
Words
count
Description Unit
23901 5D5D 1 Output allocation analog OUT2
0: U12 (V)
1: U23 (V)
2: U31 (V)
3: V1 (V)
4: V2 (V)
5: V3 (V)
6: I1 (A)
7: I2 (A)
8: I3 (A)
9: In (A)
10: F (Hz)
11: ∑P (W)
12: ∑Q (var)
13: ∑S (VA)
14: ∑PFL (%)
15: ∑PFC (%)
23902 5D5E 1 Value at 0 or 4 mA from analog output OUT 2
(-20000 to +20000)
-
23903 5D5F 1 Unit at 0 or 4 mA from analog output OUT2
0: /
1: k
2: M
23904 5D60 1 Value at 20 mA from analog output OUT 2
(-20000 to +20000)
-
23905 5D61 1 Unit at 20 mA from analog output OUT2
0: /
1: k
2: M
AnnexeII-27.Setupcustomtime
Function 3, 6 and 16 Codes
Dec.
Address
Hex.
Address
Words
count
Description Unit
24064 5E00 1 Custom1 Mode
0: Not Used
1: For TON
2: For TOF
24065 5E01 1 Custom1 Validation Type
0: By MODBUS
1: By Input
2: Auto
24066 5E02 1 Custom1 Frequency
0: Daily
1: Weekly
2: Bi Weekly
3: Monthly
4: Yearly
5: Non Cyclic
24067 5E03 4 Custom1 Start Time Date Time
24071 5E07 4 Custom1 End Time Date Time
24075 5E0B 1 Custom2 Mode
0: Not Used
1: For TON
2: For TOF
24076 5E0C 1 Custom2 Validation Type
0: By MODBUS
1: By Input
2: Auto
