socomec ATyS r User Manual


EN
ATYSp - 542001E - SOCOMEC
AnnexeII-5.Currenttransformersetting
Function 3, 6 and 16 Codes
Dec.
Address
Hex.
Address
Words
count
Description Unit
57345 E001 1 Current Transformer secondary:
1: 1 A
5: 5 A
57346 E002 1 Current Transformer primary A
AnnexeII-6.Hour/Datesetting
Function 3 and 16 Codes
Dec.
Address
Hex.
Address
Words
count
Description Unit
57600 E100 1 Day 
57601 E101 1 Month 
57602 E102 1 Year 
57603 E103 1 Hour 
57604 E104 1 Minute 
57605 E105 1 Second 
AnnexeII-7.Ethernetmoduleinterface
Function 3, 6 and 16 Codes
Dec.
Address
Hex.
Address
Words
count
Description Unit
57616 E110 1 Ethernet IP address - part 1 0 - 255
57617 E111 1 Ethernet IP address - part 2 0 - 255
57618 E112 1 Ethernet IP address - part 3 0 - 255
57619 E113 1 Ethernet IP address - part 4 0 - 255
57620 E114 1 Ethernet GATE - part 1 0 - 255
57621 E115 1 Ethernet GATE - part 2 0 - 255
57622 E116 1 Ethernet GATE - part 3 0 - 255
57623 E117 1 Ethernet GATE - part 4 0 - 255
57624 E118 1 Ethernet MASK - part 1 0 - 255
57625 E119 1 Ethernet MASK - part 2 0 - 255
57626 E11A 1 Ethernet MASK - part 3 0 - 255
57627 E11B 1 Ethernet MASK - part 4 0 - 255
57628 E11C 1 DHCP used
1: yes
0: no
57629 E11D 1 MODBUS gateway enabled
1: yes
0: no
57630 E11E 1 MODBUS RTU over Ethernet Enabled
1: yes
0: no
57631 E11F 1 Gateway External MODBUS Baudrate enumeration
0: 2400 bps
1: 4800 bps
2: 9600 bps
3: 19200 bps
4: 38400 bps
