EN
ATYS๎ฐp - 542001E - SOCOMEC
5.5. ATyS๎ฎp๎ACCESSORIES๎AVAILABLE
BRIDGING๎BARS
To connect switch I & II load terminals together.
VOLTAGE๎SENSING๎AND๎POWER๎SUPPLY๎KIT
Allows voltage sensing and power supply connections from
switch terminals to power supply and control module. Secure
cables tray, no speci๎ชc cable protection required (fuse type).
TERMINAL๎SHROUDS๎(125๎TO๎630๎A)
Incoming and outgoing protection against direct contact with
the connection terminals or parts. Cannot be mounted in the
rear position at the same time as the voltage sensing and
power outlet kit or the bridging bars.
Can be mounted top or bottom, in front or in rear position.
TERMINAL SCREENS
Incoming and outgoing protection against direct contact with
the connection terminals or parts.
REMOTE INTERFACES D20
โข Remote Display: Allows source supply state and switch
positions to be displayed remotely.
โข Remote Control: Allows remote con๎ชguration, control and
metering (from front panel) on which the device is mounted.
Typically door mounted or โค3m away from the ATyS.
DOOR ESCUTCHEON PLATE
An accessory to be ๎ชxed onto a cabinet door to frame the
controller part of ๎ซush mounted ATyS๎ฐp transfer switches.
CURRENT TRANSFORMERS
An extensive range of CTโs is available from SOCOMEC. Refer
to the SOCOMEC general catalogue for details.
COMMUNICATION๎CABLE
RJ 45 communication cable (3m long) for use with the D20
remote display/controller or Ethernet modules.
DC๎POWER๎SUPPLY๎(DC๎->๎AC)
Allows a standard 230๎ฐVAC ATyS๎ฐp to be supplied through a
12/24/48๎ฐVDC Aux Power supply.
SUPPLEMENTARY๎AUXILIARY๎CONTACT๎(AC)
Pre-breaking and signaling of positions I and II: 1 additional
auxiliary contact NO / NC auxiliary contact in each position.
Included as standard for ratings from 2000 to 3200๎ฐA. For
Low level AC: please consult SOCOMEC.
KEY๎LOCK๎AUTO๎/๎MANUAL๎SELECTOR๎SWITCH
The ATyS๎ฐp mode selector switch is delivered with a rotary
handle as standard. This can be replaced with a key lock.
RONIS๎KEY๎PADLOCKING๎ACCESSORIES
Locking of the electrical and manual operation by means of
a RONIS EL11AP lock. Possibility of locking in all positions, if
the โPadlocking in the 3 positionsโ option is ordered.
Not compatible with ๎ซush mounting.
PADLOCKING๎IN๎3๎POSITIONS
Allows locking of the operation in the 3 positions I, 0 and II.
(Factory ๎ชtted accessory)
CONTROL VOLTAGE TRANSFORMER
Allows a standard 230 V AC device to be supplied with
400๎ฐVAC.
MOUNTING๎SPACERS๎(125๎TO๎630๎A)
Raises the deviceโs terminals 10 mm away from the
backplate or frame
OPTIONAL MODULES
Communication modules (3 Types)
Con๎ชguration, Monitoring and control of the changeover
switch via Ethernet / Ethernet Gateway (RJ45 connection) or
MODBUS, (2 or 3-wire RS485 link).
Besides communication, the Ethernet module includes
Webserver monitoring integrated in the module. This gives
remote user friendly access (through internet) to ATyS๎ฐp
setting parameters, history of events, metering, engine
exerciser settings without the need for additional software.
Con๎ชguration of the ATyS๎ฐp is recommended to be done
using the SOCOMEC Easy Con๎ชg software used with a
standard laptop/computer having an RJ45 connection (to
use with the Ethernet module) or a USB connection (used
with a USB/RS485 converter) for MODBUS modules.
Input / Output Extension Module
2 Inputs/2 Outputs on each module with a maximum of 4
modules on each ATyS๎ฐp. (Attn: When used with an Ethernet
module the remaining space available is for 2 I/O modules.
Similarly when used with a Modbus module the remaining
space available is for 3 I/O modules.
4-20mA analogue output module
3I, In, 3V, 3U, F, ยฑ ฮฃP, ยฑ ฮฃQ, ฮฃS
๎๎ค๎๎๎๎๎๎ท๎๎๎
๎๎๎๎๎๎ฐ๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎
Pulsed output module
2 con๎ชgurable pulse outputs (type, weight and duration) on
ยฑ๎ฐkWh, ยฑ kvarh and kVAh
๎๎ค๎๎๎๎๎๎ท๎๎๎
๎๎๎๎๎๎ฐ๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎๎
Others:๎
Refer to the end of this instruction manual or the latest
SOCOMEC product catalogue.
(Downloadable from www.socomec.com)
