Description Unit
22795 590B 1 Manual retransfer
0: NO
1: YES
22799 590F 1 BackLight
0: ON
1: OFF
2: INT
22800 5910 1 Current transformer (Pri) -
22801 5911 1 Current transformer (Sec)
1: TCsec = 1A
5: TCsec = 2A
22802 5912 1 Invert Source 1 and Source 2
0: Not inverted
1: Inverted
AnnexeII-21.SetupInput/Output
Function 3, 6 and 16 Codes
Dec.
Address
Hex.
Address
Words
count
Description Unit
23040 5A00 1 In 5 - StartGen board input 1 function
0: --- - None
1: INH - Inhibition
2: TON - Test on load
3: TOF - Test off load
4: EON - External order on load
5: EOF - External order off load
6: RTC - Retransfer
7: PRI - Priority
8: SS1 - Validation Stabilization source 1
9: SS2 - Validation Stabilization source 2
10: AL1 - Alarm 1
11: AL2 - Alarm 2
12: FT1 - Fault 1
13: FT2 - Fault 2
14: MSR - Power priority
15: OA1 - Override source 1 available
16: OA2 - Override source 2 available
17: RST - Reset faults state
18: LSI - Load shedding
19: TR1 - Time Range1 Validate
20: TR2 - Time Range2 Validate
21: TR3 - Time Range3 Validate
22: TR4 - Time Range4 Validate
24: CHP - Change of position
