socomec ATyS r User Manual

129
EN
ATYSp - 542001E - SOCOMEC
Dec.
Address
Hex.
Address
Words
count
Description Unit
23078 5A26 1 Out 2 state
(only with 2IN2OUT module #1)
0: NO
1: NC
23079 5A27 1 Out 3 state
(only with 2IN2OUT module #1)
0: NO
1: NC
23080 5A28 1 Out 4 state
(only with 2IN2OUT module #2)
0: NO
1: NC
23081 5A29 1 Out 5 state
(only with 2IN2OUT module #2)
0: NO
1: NC
23082 5A2A 1 Out 6 state
(only with 2IN2OUT module #3)
0: NO
1: NC
23083 5A2B 1 Out 7 state
(only with 2IN2OUT module #3)
0: NO
1: NC
23084 5A2C 1 Out 8 state
(only with 2IN2OUT module #4)
0: NO
1: NC
23085 5A2D 1 Out 9 state
(only with 2IN2OUT module #4)
0: NO
1: NC
AnnexeII-22.Communicationsettings
Function 3, 6 and 16 Codes
Dec.
Address
Hex.
Address
Words
count
Description Unit
23296 5B00 1 MODBUS Address -
23297 5B01 1 UART Baud Rate
2: 9600 bps
3: 19200 bps
4: 38400 bps
23298 5B02 1 UART Parity
0: none
1: even
2: odd
23299 5B03 1 UART Stop bit number
1: 1 stop bit
2: 2 stop bits
23300 5B04 2 IP Product -
23302 5B06 2 IP Mask -
23304 5B08 2 IP Gateway -
23306 5B0A 1 DHCP Enabled
0: No
1: Yes
23307 5B0B 8 Product identication -
