ATYSp - 542001E - SOCOMEC
AnnexeII-13.Timersstate
Function 3 Codes
Dec.
Address
Hex.
Address
Words
count
Description Unit
21248 5300 2 Date & Time Current sec.
21250 5302 1 Source 1: SFT Timer / 1FT sec.
21251 5303 1 Source 1: SAT Timer / 1RT sec.
21253 5305 1 Source 2: SFT Timer / 2FT sec.
21254 5306 1 Source 2: SAT Timer / 2RT Or 2AT sec.
21255 5307 1 Source 2: LAT Timer / 2CT sec.
21257 5309 1 Source 2: FST Timer / 2ST sec.
21258 530A 1 DBT Timer / 0DT sec.
21259 530B 1 LoadShedding Timer (duration) / LST sec.
21260 530C 1 TON is unlimited
0: limited
1: unlimited
21261 530D 1 TON (Test On Load Duration) Timer sec.
21262 530E 1 T3T (Test on load end timer) Timer sec.
21263 530F 1 TOF is unlimited
0: limited
1: unlimited
21264 5310 1 TOF (Test Off Load Duration) Timer sec.
21265 5311 1 STOLT (Time before Ord. Ext On Load) Timer / E1T sec.
21266 5312 1 ETOLT (Time after Ord. Ext On Load) Timer / E3T sec.
21267 5313 1 EOLTOT / E2T is unlimited
0: limited
1: unlimited
21268 5314 1 EOLTOT (Ord. Ext On Load Duration) Timer / E2T sec.
21269 5315 1 STOFT (Time before Ord. Ext Off Load) Timer / E5T sec.
21270 5316 1 ETOFT (Time after Ord. Ext Off Load) Timer / E7T sec.
21271 5317 1 EOFTOF / E6T is unlimited
0: limited
1: unlimited
21272 5318 1 EOFTOF (Ord. Ext Off Load Duration) Timer / E6T sec.
21273 5319 1 EET2: Secondary Source engine exerciser timeout / EET hours
21274 531A 1 EDT2: Secondary Source engine exerciser duration / EDT sec.
21275 531B 1 Source 1: SFT Timer / 1FT state
1: Active
0: Not active
21276 531C 1 Source 1: SAT Timer / 1RT state
1: Active
0: Not active
21277 531D 1 Source 1: 0RT Timer / 1OT state
1: Active
0: Not active
21278 531E 1 Source 2: SFT Timer / 2FT state
1: Active
0: Not active
21279 531F 1 Source 2: SAT Timer / 2RT Or 2AT state
1: Active
0: Not active
