S6 Portable Digital Color Doppler Ultrasound System
Service Manual
6
Gynecology and fertility
6
Cardiology
6
Urology
6
Musculoskeletal
Note: The application fields are dependent on the probe in use.
Warning!
The S6 system is not intended for ophthalmic use or any use
causing the acoustic beam to pass through the eye.
3.4 Operating Modes
6
B Mode
6
B FLOW
6
Tissue Harmonic Imaging (THI)
6
M Mode
6
Color Doppler Imaging (CDI or CFM)
6
Power Doppler Imaging (DPI)
6
Directional Power Doppler Imaging (DDPI)
6
Pulsed Wave Doppler Imaging (PW)
6
Continuous Wave Doppler Imaging (CW)
6
Tissue Doppler Imaging (TDI)
3.5 Combined Modes
The system provides the following Duplex modes with some in dual display
format.
Notations: Left means left screen, Up means upper screen. Similar for
Right and Down, e.g., Left B+COLOR, Right B implies that the left screen
is of duplex mode, B and CFM, and the right screen is of B mode.
6
Left B, Right B
6
Left B+COLOR, Right B;
6
Left B+COLOR, Right B+COLOR
P/N: 4720-0034-01A
3-5
