S6 Portable Digital Color Doppler Ultrasound System
Service Manual
Chapter 9
Supported Peripherals
9.1 Introduction
The S6 system currently supports the following peripherals:
A. Network printer
B. PC with Windows XP (SP2/SP3) installed
C. USB 2.0 removable disk
D. Thermal printer
When connecting the device A or B to the S6 system, both the device and
the ultrasound system must be properly configured before they are opera-
tional. Other devices listed above are ready to use after being connected to
the S6 system, no configuration is required.
The S6 system currently only supports network printers and thermal print-
ers . Some supported printer models are listed in the section 9.3. It’s rec-
ommended to consult the service center of SonoScape if the user intends to
use a printer model not in the support list. SonoScape will test the printer
models based on market demand and extend the range of supported printer
models for the S6 system.
The user can access the cine files (images or videos) on the S6 system
remotely using a PC which has been connected through Ethernet.
9.2 Thermal Printer Installation
Thermal printer (or video printer), may be connected to the ultrasound
system directly with the BNC or S-VIDEO cable provided. The printer con-
troller should be connected to the printer controller port on the ultra-
sound system. The printer is ready to use immediately after connection,
with no configuration required. SONY UP-20 color-video and UP 895MD
P/N: 4720-0034-01A
9-1
