S6 Portable Digital Color Doppler Ultrasound System
Service Manual
Chapter 6
Wiring Instructions
6.1 Introduction
This chapter contains information for wiring inside the system. Section 6.2
gives the general information and precautions for connecting miscellaneous
parts/units. Section 6.3 includes details on how to make each connection
in the correct way.
Contents
6.1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
6.2 Wiring in the System Level . . . . . . . . . . . . . . . . . . . . . 6-2
6.3 Detailed Connection Instructions . . . . . . . . . . . . . . . . . 6-4
6.3.1 Control Cable for Keyboard Unit (3520-0501) . . . . 6-4
6.3.2 Connection wires for keyboard small board (3520-
0502) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
6.3.3 Connection wires for trackball (3520-0503) . . . . . . 6-4
6.3.4 Connection cable for loud speakers (3520-0504) . . . 6-5
6.3.5 Signal Transmission cable for keyboard (3520-0505) 6-5
6.3.6 SATA cable for HDD (3520-0506) . . . . . . . . . . . . 6-6
6.3.7 LVDS Signal Cable (3520-0507) . . . . . . . . . . . . . 6-6
6.3.8 Cables Connecting Keyboard and motherboard (3520-
0508) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7
6.3.9 Connection wires for system fan(3520-0509) . . . . . 6-7
6.3.10 DBF USB Signal Cable (3520-0510) . . . . . . . . . . 6-7
6.3.11 USB Cable for µ-Scan Dongle(3520-0511) . . . . . . 6-8
6.3.12 Power Supply Cable for Voltage Inversion Board (3520-
0512) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8
6.3.13 ECG internal connection cable (3520-0513) . . . . . 6-9
6.3.14 Foot Switch Cable (3520-0514) . . . . . . . . . . . . . 6-9
6.3.15 Composite Video BNC Cable (3520-0515) . . . . . . . 6-9
6.3.16 Main power cables from SMPS (3520-0520) . . . . . 6-10
P/N: 4720-0034-01A
6-1
