Sonoscape S6 Service Manual

S6 Portable Digital Color Doppler Ultrasound System
Service Manual
6 Persistence range: from 0 to 95, may vary with the probes
6 Line Density: 3 level adjustable (high/medium/low)
6 Chroma: 13 different colors available
6 Adaptive Image Fusion: 6 level adjustable
6 Tissue Characteristic Index: adjustable from 1400 to 1700
6 Image Orientation: flip vertically and/or horizontally
3.7.2 Spectral Doppler (PW/CW)
Image/Video Parameters
6 Video inversion
6 Flow Inversion
6 Sweep Speed: 4 level adjustable
Signal Processing
6 Dynamic Range: 5 level adjustable
6 Chroma: 5 different colors available
6 D Gain: adjustable from 1 to 255
6 Doppler Angle Correction: adjustable from -80 to 80 degrees
6 Sound Volume Adjustable
3.7.3 Color Doppler and Power Doppler
Signal Processing
6 D Gain: adjustable from 1 to 255
6 Persistence Range: 0 to 80 (also depends on the probe in use.)
6 Color Mapping: 4 options available
6 B-Reject Range: from 0 to 255
6 Baseline: 31 level adjustable.
P/N: 4720-0034-01A
3-7
