30
(E)
Chapter 2 Menu
Menu Structure
Menus consist of one to three levels.
Detailed information on the levels of menus is
described at the top of explanation of each menu.
Main Menu Functions
A CONTROL PRESET ADJ menu Sets the preset values for the input signal’s chroma, contrast,
phase, and brightness. (page 31(E))
B COLOR TEMP ADJ menu Sets the color temperature. (page 33(E))
C INPUT CONFIG menu Sets the input channel. (page 35(E))
D REMOTE menu Sets the remote control functionality. (page 37(E))
E SYSTEM CONFIG menu Sets the power-up conditions and data about the screen display.
(page 39(E))
F STATUS menu Displays the information about the monitor or options installed in
the monitor. (page 42(E))
G ALIGNMENT menu Adjusts the position, size and geometry of the picture. (page
43(E))
The preliminary adjustments of chroma, phase,
contrast and brightness are carried out with the
CONTROL PRESET ADJ menu to set the preset
values to the knobs for the above-mentioned
adjustments.
Preset values can be set in the following two ways:
•Adjustment with the MANUAL adjustment knobs
(MANUAL menu)
•Automatic adjustment (AUTO menu)
An external color bar signal is necessary.
Note
After installing the optional board, carry out AUTO
adjustment.
This section explains the setting lists displayed in the
menu.
How to read the setting lists
•For purposes of explanation, each setting list is
preceded by a menu number. These numbers are not
displayed on the screen.
For more information about the menu number, see “About
menu numbers” on page 26(E).
Overview
•The arrow mark (÷) refers you to another setting list
that appears after you make the setting, or to an
operation that is carried out as a result of the setting.
When there is no arrow mark, the menu does not have
any sub-list.
Setting Lists in the CONTROL PRESET ADJ Menu
Structure of the CONTROL PRESET ADJ Menu
A Preset Adjustment of the Picture Level Control
Knobs — CONTROL PRESET ADJ Menu
Level 1 Level 2
To Next Page
