46
(E)
Chapter 2 Menu
Cancelling the Remote Control
Mode
To cancel the remote control mode, press the
ADDRESS button.
Exiting the ADDRESS Menu
To exit the ADDRESS menu, press the ADDRESS
button or the MENU button.
Short-cut Function in the
ADDRESS Menu
When selecting the monitor, short-cut function will
enable to select the target monitor without using the
items in the ADDRESS menu. The operation
procedure is as follows.
To select the monitor in the SINGLE mode
1
Press the ADDRESS button.
2
Press the address number of the target monitor.
Press one digit address number on the numeric
keypad when it is from 1 to 9.
Press three digits address number (press 0 button
and then press the two-digit address number) when
it is from 10 to 99.
To select the monitors in the GROUP mode
1
Press the ADDRESS button.
2
Press the F1 button.
3
Press the group number of the target monitor.
Press one digit group address number when it is
from 1 to 9.
Press three digits group address number (press 0
button and then press the two-digit group number)
when it is from 10 to 99.
To select all the monitors in the ALL mode
1
Press the ADDRESS button.
2
Press the F2 button.
Selecting the Monitor to Control — ADDRESS Menu
47
(E)
Chapter 3 Appendix
Nominal chromaticity coordinates:
EBU phosphor
Dimensions (w/h/d)
BVM-D9H1U/D9H1E/D9H1A:
approx. 217 × 174 × 364.5mm
(8
5
/
8
× 6
7
/
8
× 14
3
/
8
inches)
when the AC adaptor is installed:
approx. 217 × 174 × 419.5mm
(8
5
/
8
× 6
7
/
8
× 16
5
/
8
inches)
BVM-D9H5U/D9H5E/D9H5A:
approx. 217 × 218 × 364.5mm
(8
5
/
8
× 8
5
/
8
× 14
3
/
8
inches)
when the AC adaptor is installed:
approx. 217 × 218 × 419.5mm
(8
5
/
8
× 8
5
/
8
× 16
5
/
8
inches)
BVM-D14H1U/D14H1E/D14H1A:
approx. 346 × 280 × 519mm
(13
5
/
8
× 11
1
/
8
× 20
1
/
2
inches)
BVM-D14H5U/D14H5E/D14H5A:
approx. 482 × 280 × 519mm
(19 × 11
1
/
8
× 20
1
/
2
inches)
Specifications
General
System 15.625 kHz – 45 kHz
(For details, see “Available Signal
Format” on page 53(E).)
CRT
BVM-D9H1U/D9H1E/D9H1A/D9H5U/D9H5E/
D9H5A
HR Trinitron, 4:3 aspect ratio
Aperture grille pitch: 0.25 mm
90 degree deflection, 21.6 mm
diameter in-line gun
Effective picture size with 16:9
aspect ratio:
155.4 × 87.4 mm (6
1
/
8
× 3
1
/
2
inches) (w/h)
178 mm (7
inches) (diagonal size)
Effective picture size with 4:3
aspect ratio:
155.4 × 115 mm (6
1
/
8
× 4
5
/
8
inches) (w/h)
190.7 mm (7
1
/
2
inches) (diagonal
size)
CRT protection: EHT (extremely
high tension) protection type
Warm-up time: approx. 30 minutes
Anode voltage: 15 kV with no
beam current
BVM-D14H1U/D14H1E/D14H1A/D14H5U/
D14H5E/D14H5A
HR Trinitron, 4:3 aspect ratio
Aperture grille pitch: 0.25 mm
90 degree deflection, 29.4 mm
diameter in-line gun
Effective picture size with 16:9
aspect ratio:
267.5 × 150.5 mm (10
5
/
8
× 6
inches) (w/h)
306.9 mm (12
1
/
8
inches)
(diagonal size)
Effective picture size with 4:3
aspect ratio:
267.5 × 200.6 mm (10
5
/
8
× 8
inches) (w/h)
331.6 mm (13
1
/
8
inches)
(diagonal size)
CRT protection: EHT (extremely
high tension) protection type
Warm-up time: approx. 30 minutes
Anode voltage: 23 kV with no
beam current
xy
R 0.640 0.330
G 0.290 0.600
B 0.150 0.060
Chapter 3 Appendix
