Structure of the SYSTEM CONFIG Menu
Level 1 Level 2
Setting Lists of the SYSTEM CONFIG Menu
This section explains the setting lists displayed in the
menu.
How to read the setting lists
•For purposes of explanation, each setting list is
preceded by a menu number. These numbers are not
displayed on the screen.
For more information about the menu number, see “About
menu numbers” on page 26(E).
•The arrow mark (÷) refers you to another setting list
that appears after you make the setting, or to an
operation that is carried out as a result of the setting.
When there is no arrow mark, the menu does not have
any sub-list.
•The factory setting is shown in the brackets.
[E] (1/2) SYSTEM CONFIG (1/2) menu
Set each of the following items.
STANDBY MODE: Select the power-up condition
when the MAIN POWER switch is turned on
(BVM-D14H1U/D14H1E/D14H1A/D14H5U/
D14H5E/D14H5A) or when the battery is installed
(BVM-D9H1U/D9H1E/D9H1A/D9H5U/D9H5E/
D9H5A.)
ON: Standby mode
[OFF]: Operation mode
DEFAULT CH: Select the power-up input channel
(LAST or CH x).
[LAST]: Set the channel to the channel that was
selected at the time the power was last turned
off.
CH x: Set the channel to a specific channel
number.
DEGAUSS DELAY: Set the time between power-up
and the beginning of degaussing. Enter the desired
time (in seconds, 0 to 255).
E Setting the Power-Up Conditions and Data about the Screen Display — SYSTEM CONFIG Menu
41
(E)
Chapter 2 Menu
CONT/BRT HOLD: Select the contrast and
brightness settings to the center or adjusted value
after adjusting the white balance or auto
adjustment of CONTROL PRESET ADJ (OFF or
ON).
ON: The contrast and brightness are set to the
value before adjusting.
[OFF]: The contrast and brightness are set to the
center value (100) after adjusting.
COL TEMP SHORT-CUT: Assign the shortcut
function to the MANUAL menu of the COLOR
TEMP ADJ menu to [F2] key (OFF or F2).
F2: Assigns the shortcut to the MANUAL menu
of the COLOR TEMP ADJ menu.
[OFF]: Does not assign the shortcut to the
MANUAL menu of the COLOR TEMP ADJ
menu.
ACC SW: Set the automatic color control switch (OFF
or ON).
CONFIG COPY...: Copy setting data of the INPUT
CONFIG and SYSTEM CONFIG (except the
DEGAUSS DELAY data) menus from the serial
connected BVM-D9H/D14H monitor. ÷[E11]
[E11] MONITOR ADDRESS menu
Set the address number of the monitor to be copied.
[E] (2/2) SYSTEM CONFIG (2/2) menu
Select items to be displayed on the screen.
FORMAT DISPLAY: Select the display mode of the
signal format. ÷[E2] (2/2)
POSITION: Select the display position of the
signal format. ÷[E2] (2/2)
CH NO: Select the display mode of the channel
number. ÷[E3] (2/2)
POSITION: Select the display position of the
channel number. ÷[E3] (2/2)
CH NAME: Select the display mode of the channel
name. ÷[E4] (2/2)
POSITION: Select the display position of the
channel name. ÷[E4] (2/2)
CAPTION: Select the caption display mode.
÷[E5] (2/2)
MAINTENANCE...: Menu for service personnel.
[E2] (2/2) FORMAT DISPLAY and POSITION
menus
FORMAT DISPLAY menu
Select the display mode of the signal format.
[AUTO]: Disappears after displayed for a while.
ON: Displayed.
OFF: Not displayed.
POSITION menu
Select the display position.
[BOTTOM LEFT]
BOTTOM CENTER
BOTTOM RIGHT
TOP LEFT
TOP CENTER
TOP RIGHT
[E3] (2/2) CH NO and POSITION menus
CH NO menu
Select the display mode of the channel number.
[AUTO]: Disappears after displayed for a while.
ON: Displayed.
OFF: Not displayed.
POSITION menu
Select the display position.
BOTTOM LEFT
BOTTOM CENTER
[BOTTOM RIGHT]
TOP LEFT
TOP CENTER
TOP RIGHT
[E4] (2/2) CH NAME and POSITION menus
CH NAME menu
Select the display mode of the channel name.
[AUTO]: Disappears after displayed for a while.
ON: Displayed.
OFF: Not displayed.
POSITION menu
Select the display position.
BOTTOM LEFT
BOTTOM CENTER
BOTTOM RIGHT
[TOP LEFT]
TOP CENTER
TOP RIGHT
[E5] (2/2) CAPTION menu
Select the caption display mode.
[OFF]: Not displayed
CAPTION 1: Displayed in CAPTION 1 mode.
CAPTION 2: Displayed in CAPTION 2 mode.
TEXT 1: Displayed in TEXT 1 mode.
TEXT 2: Displayed in TEXT 2 mode.
To Next Page
