13.1 Performance
Aspect Detail
Equipment designation Healthcare sonic irrigator
Classifications
Medical device class I
Class 1 electrical shock protection, externally powered
No applied parts
IP rating: IPX0
Not suitable for use in oxygen-rich environment
Designed for continuous use
Intended purpose Internal and external cleaning of surgical instruments, hollow-
ware, and associated products.
Operating process Ultrasonic activity, irrigation ports, and water heating.
Ultrasonic system 18 piezoelectric transducers typically operating at 38kHz to
40kHz dependent on load. 40 W power per transducer.
Pulsed degas, auto-tune, frequency sweep.
Irrigation system Twin 4-port manifolds on 2 corners of basket producing up to
1.5 bar (22.0 psi) at a flow rate of 2.9 liters/min.
(98.1fl.oz./min.)
Water temperature
monitoring
Measurement range: +2 ºC to +60 ºC (+36 ºF to +208 ºF)
Temp. display: +5 ºC to +60 ºC (+41 ºF to +140 ºF),
accuracy ±0.5.
Drainage system Equipment-operated valve and drain pump
Drain outlet 19 mm (3/4 in.) hose tail
Effluent temperature Max. +60 ºC (+140 ºF)
Maximum drain flow rate 30 liters/min. (8 USgal/min.)
User interface 4.3 in. TFT touch-screen display
Audio 1 W speaker
Time Control accuracy: ±0.5 second.
Display: minutes and seconds.
Internal data storage Micro SD flash card, >4 GB (storage of >10,000 cycles)
Real-time clock battery CR1220 (5012LC), 35 mAh to 40 mAh, 0.1 mA
108 SPECIFICATION
InnoWave Unity & Unity 20 Operator Manual
