Series 4180 Powerhead 47
17.1 Tools
17 Tools, Servicing Aids
Part No. Part Name Application
0000 850 1300 Pump Testing crankcase and tank vent for leaks
0000 855 8106 Sealing plate Sealing exhaust port
0000 855 9200 Nipple For pump
0000 890 2305 Screwdriver Disconnecting throttle rod
0000 893 3706 Jaws (No. 3.1) Removing oil seals
0000 893 3707 Jaws (No. 9) Removing AV rubber element
0812 542 2104 Socket bit, T27x125 Removing and installing spline socket screws with
electric or pneumatic screwdrivers; tightening
down screws with torque wrench
0816 610 1495 Pliers, A10 flat Removing and installing retaining ring
1108 893 4700 Assembly drift Sealing impulse hose for engine leakage test
1110 141 8600 Hose, 135 mm Testing carburetor for leaks
1110 893 4700 Assembly drift Removing piston pin
1114 893 4700 Assembly drift Installing piston pin
1120 893 2400 Sleeve Removing clutch drum
4112 893 2401 Press sleeve Installing oil seal
4118 890 6401 Setting gauge Setting air gap for ignition
4119 890 4501 Puller Removing the Flywheel
4119 893 2400 Press sleeve Installing clamp and rubber element
4180 890 8600 Retainer Blocking crankshaft for leakage test
4180 893 4400 Extension Removing and installing clutch drum
4180 893 6400 Setting gauge Adjusting valve clearance
4282 890 2700 Locking screw Blocking the crankshaft
5910 850 0300 Leakage tester Testing pressure loss
5910 850 2000 Compression tester Testing valves and piston rings for leaks
5910 850 4200 Flange Testing engine for leaks
5910 850 4503 Ignition system tester, ZAT 4 Testing the ignition system
5910 850 4520 Ignition system tester, ZAT 3 Testing the ignition system
5910 890 0302 Torque wrench with optical/acoustic signal 1 to 18 Nm
5910 890 0312 Torque wrench with optical/acoustic signal 10 to 80 Nm
5910 890 2204 Installing tool Installing rope guide bushing
5910 890 2208 Installing tool 8 Snap ring, 8 mm diameter piston pin
5910 890 2209 Installing tool 9 Snap ring, 9 mm diameter piston pin
5910 890 2301 Screwdriver, T20 Star socket screws, installing and removing
5910 890 2307 Screwdriver Disassembling the carburetor
5910 890 2308 Screwdriver, T10 Star socket screws, installing and removing
5910 890 2310 Screwdriver, T8 Star socket screws, installing and removing
5910 890 2415 Screwdriver, T27x200 Star socket screws, installing and removing
5910 890 2420 Screwdriver, Q-SW 8-200 Removing filter housing
5910 890 3101 Assembly stand Holding powerhead
5910 890 4000 Punch-down tool Installing short circuit and ground wires
5910 890 4400 Puller Removing oil seals and AV rubber element
5910 893 2804 Socket, 13 mm, long Removing and installing flywheel and starter cup
5910 893 7005 Ring Removing clutch drum
5910 893 8800 Hook Removing and installing pickup body
0781 120 1110 STIHL multipurpose grease, 225 g tube Lubricating contact springs in loop handle
0781 957 9000 STIHL OH 723 press fluid, 50 ml bottle Installing hoses and AV rubber element
0783 830 2000 Dirko HT red sealant, 70 ml tube Sealing engine pan
